What is Google ADK?

Google Agent Development Kit (ADK) is an open-source framework for building, orchestrating, and deploying AI agents. It provides:

LlmAgent: A single agent backed by a Gemini model that can reason, plan, and call tools
SequentialAgent: Chains multiple agents together so each one processes the output of the previous
Tools: Python functions wrapped so an agent can call them (e.g. run SQL, call an API, mask data)
MCP Toolset: Connects ADK agents to any Model Context Protocol server, giving them external capabilities
Runner + Sessions: Manages stateful multi-turn conversations between users and agents
adk web: A built-in local UI to chat with your agents instantly — no frontend code needed

In this project, ADK orchestrates three agents in a pipeline: a security judge, a SQL analyst, and a data masker — all coordinated automatically by a SequentialAgent.

System Architecture

The system utilizes a layered architecture:

A2A Protocol Layer: Provides standardized communication between clients and agent services
ADK Framework Layer: Manages agent behavior and tool integration
MCP Server Layer: Provides specialized SQL and data processing tools

Components

A2A Servers: Handle client requests and agent communication
ADK Agents: Process natural language requests using specialized tools
MCP Server: Provides SQL query and database interaction tools
Task Managers: Coordinate task execution across agents

Agent Pipeline

The system implements a security pipeline with three specialized agents:

Judge Agent: Evaluates input for security threats (SQL injection, XSS, etc.)
SQL Agent: Performs database queries and analysis using MCP tools
Mask Agent: Applies privacy protection to sensitive data in results

Flow Diagram

Client Request → A2A Server → Judge Agent → SQL Agent → Mask Agent → Client Response

Key Features

Security Threat Detection: Identifies and blocks malicious inputs via tool and Model Armor
SQL Query Analysis: Processes database queries using natural language
PII Data Protection: Masks personally identifiable information in results using DLP
A2A Protocol Compliance: Implements standardized agent communication
MCP Integration: Leverages Model Context Protocol tools for enhanced capabilities

Installation

Prerequisites

Python 3.8+
aiohttp
FastAPI
Google ADK
Google Generative AI packages
uvicorn

Setup

Clone the repository
Install dependencies: pip install -r requirements.txt
Copy agents/.env.example to agents/.env and fill in your credentials (see below)
Have fun

Configuration

Copy agents/.env.example to agents/.env. You have two options:

Option 1 — Gemini API key only (no GCP required, easiest)

GOOGLE_GENAI_USE_VERTEXAI=FALSE
GOOGLE_API_KEY=your-gemini-api-key-here

Get a free key at aistudio.google.com. No GCP account needed.

Option 2 — Google Cloud Vertex AI (for production / GCP users)

GOOGLE_GENAI_USE_VERTEXAI=TRUE
GOOGLE_CLOUD_PROJECT=your-gcp-project-id
GOOGLE_CLOUD_LOCATION=us-central1

Requires gcloud auth application-default login and a GCP project with Vertex AI enabled.

Usage

Starting the Servers

Run the adk web script to run the chat interface:

adk web

This will start:

Judge Server (port 10002)
Mask Server (port 10003)
SQL Server (port 10004)
MCP Server

Making Requests

Run the query_MCP_ADK_A2A.py script to query the multi-agent system:

python ./clients/query_MCP_ADK_A2A.py

This will use the a2a_client.py module to make requests to the pipeline:

Core Files

a2a_client.py: Client for A2A communication
a2a_servers.py: Server implementations for A2A protocol
query_MCP_ADK_A2A.py: Main pipeline implementation
run_servers.py: Server startup and coordination
server_mcp.py: MCP server implementation
task_manager.py: Task coordination for agent communication
mcp_agent.py: Integration between ADK and MCP

MCP Integration

The system integrates with Model Context Protocol (MCP) for enhanced SQL capabilities:

# Connect to MCP server
tools, exit_stack = await MCPToolset.from_server(
    connection_params=StdioServerParameters(
        command='python',
        args=["server_mcp.py"],
    )
)

# Create ADK agent with MCP tools
agent = LlmAgent(
    model='gemini-2.0-flash',
    name='sql_assistant',
    instruction="...",
    tools=tools,
)

Security Features

Pattern-based security threat detection
PII identification and masking (emails, names, addresses, etc.)
Input sanitation with whitelist approach
Model Armor API integration for additional protection

Deployment

Testing:

docker build -t adk-multi-agent .
docker run -p 8000:8000 -e GOOGLE_API_KEY=your_api_key adk-multi-agent adk web

Production:

export GOOGLE_CLOUD_PROJECT=your-project
export GOOGLE_CLOUD_LOCATION=us-central1
export GOOGLE_GENAI_USE_VERTEXAI=True
export AGENT_PATH="."
export SERVICE_NAME="adk-agent-service"
export APP_NAME="agents"

adk deploy cloud_run \
--project=$GOOGLE_CLOUD_PROJECT \
--region=$GOOGLE_CLOUD_LOCATION \
--service_name=$SERVICE_NAME \
--app_name=$APP_NAME \
--with_ui \
$AGENT_PATH

Documentation

Agent Development Kit Documentation

A2A Protocol Documentation

MCP Server Documentation

Contributing

Fork the repository
Create a feature branch
Submit a pull request with comprehensive description

This project demonstrates integration between A2A protocol and MCP server capabilities, creating a secure and flexible agent architecture for data processing.
